Swing over bed 673mm. Swing over carriage 374mm. Distance between centres 1000mm.Max machining length 1024mm. X Axis travel 228mm. Y axis travel 101mm. Z axis travel 1095mm. Spindle speeds 0-4000 rpm.Spindle nose A2-8. Rapids X/Z 30m min/33m min. Bar capacity 77mm.12 station turret. Driven tooling. Milling speed 4500 rpm. Main motor (30 min rating) 26 kW. Mazatrol Matrix Nexus Control. Collet chuck. Sub spindle (Kitagawa B206). Swarf conveyor. Automatic tool eye. Axial/Radial Toolholders. Coolant – High pressure 213 PSI. Parts catcher. Multifeed Barfeed. Filtermist S800. Swarf Conveyor.
Machine dimensions L x W x H 2641mm x 1778mm x 1855mm high. Weight 5700kgs
