Longitudinal travel 3000mm. Vertical Travel 2200mm. Ram Travel 1300mm. Spindle speeds to 5000 rpm. Rapids 35m/min. No. of tools in Auto tool changer 30. Maximum dia. of tool in adjacent positions 125mm. Maximum dia. of tool in alternate positions 250mm. Maximum length of tool (exc. taper) 400mm. Maximum weight of tool 20Kg. Maximum thrust of shaft to cutting unit 16,000 N. Motor power 32kW. Mandrel headstock cone DIN-69871-AD.Total installed power 57kW. Machine fitted with an automatic positioning universal head. Swarf conveyor. Hydraulic tank with cooling system. Integrated electrical panel with air conditioning.Renishaw probing. Coolant & filtration unit.
DEMMELER Model DRTB1200/1800/1800 Rotary Table. Loading capacity 10,000 kg. Weight of table 5,000kg. Size of table surface 1800mm x 1800mm. Overall dimensions of table L x W x H 2030mm x 1800mm x 500mm. Rotational speed of rotary table 0-4.9 rpm.Motor rotational speed 3,000 rpm.
Machine dimensions L x W x H 8735mm (includes swarf conveyor) x 6000mm (includes rotary table) x 4350mm high. Approximate weight 27,000 kgs
